3001 RANGE



The first Vitrocsa 3001 window was developed at the start of the 1990's. With the experience we now have, we can guarantee that this system has no hidden defects. The roller mechanism and sealing system work perfectly, provided that the window has been assembled in line with good industry practices.




SPECIFICATIONS





Rail + Frames

  • Embedded and concealed in the floor, wall and ceiling
  • Frame just 99.5 mm wide for a Birail (Mono: 45 mm + 9.5 mm seal)
  • Saline treatment specially adapted for costal projects

Clousure Mechanism

  • Standard closure mechanism (029, 035, 005)
  • Cylinder
  • Range of options for electric closure
  • Alarms



Vertical connection

  • 18.5  mm
  • Reinforced for very windy locations or installation at high altitudes

Glazing

  • 26mm
  • Panel size up to 6 m²

Configuration

  • Standard sliding frame (up to 6 m²)
  • Pivoting (up to 6 m²)
  • Guillotine (up to 6 m²)
  • Fixed (up to 9 m²)
  • Open angle
  • Pocket
  • Motorisation
  • Mosquito net
