V32 RANGE



The V32 range has thermal reinforcement and a glass fibre profile. This range is designed for standard fixed or sliding openings.




SPECIFICATIONS





Rail + Frames

  • Embedded and concealed in the floor, wall and ceiling
  • Frame just 124 mm wide for a Birail (Mono: 56 mm + 12 mm seal)
  • Saline treatment specially adapted for costal projects

Clousure Mechanism

  • Two-point closure button
  • Cylinder
  • Range of options for electric closure
  • Alarms



Vertical connection

  • 23  mm
  • Reinforced for very windy locations or installation at high altitudes
  • Optimised heat retention with fibreglass towers

Glazing

  • 32 mm
  • Panel size up to 12 m² (4 x 3m), vertical or horizontal

Configuration

  • Sliding (up to 12 m²)
  • Fixed (up to 12 m²)
  • Open angle
  • Pocket
