V32 RANGE


V32 RANGE

The V32 range has thermal reinforcement and a glass fibre profile. This range is designed for standard fixed or sliding openings.



SPECIFICATIONS



Rail + Frames

  • Embedded and concealed in the floor, wall and ceiling.
  • Frame just 124mm wide for a Birail (Mono: 56mm + 12mm seal).
  • Saline treatment specially adapted for coastal projects.

Vertical connection

  • 20mm.
  • Reinforced for very windy locations or installation at high altitudes.
  • Optimised heat retention with fibreglass towers.

Configuration


  • Sliding (up to 12m²).
  • Fixed (up to 12m²)
  • Open angle.
  • Pocket.

  • Two-point closure button.
  • Cylinder.
  • Range of options for electric closure.
  • Alarms.

Closure Mechanism


  • 32mm.
  • Panel size up to 12 m² (4 x 3m), vertical or horizontal.

Glazing
